Soundigital evo 5 sd1600.1 1 ohm

Product beschrijving

The 1600.1 EVO 5 is a compact, modern amplifier that delivers 1600W RMS of power over 1 channel.
The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.
Power @ 4Ω: 1 X 697 WRMS Power @ 2Ω: 1 X 1056 WRMS Power @ 1Ω: 1 X 1600 WRMS
Frequency Response (-3dB): 5Hz ~ 25kHz Subsonic Filter: 5Hz ~ 80Hz Low Pass Filter: 50Hz ~ 1kHz Bass Boost: 0dB ~ 12dB @ 50Hz Operating Voltage: 9V ~ 16V
Signal-Noise Ratio:
1Ω: 93.7dB 2Ω: 95dB 4Ω: 93.4dB
Input Sensitivity: 0.2V ~ 2V
Current Draw (Music):
1Ω: 75A 2Ω: 71A 4Ω: 69.4A
Current Draw (Max):
1Ω: 149A 2Ω: 143A 4Ω: 138.8A
Total Efficiency:
1Ω: 85% 2Ω: 89% 4Ω: 91.5%
Damping Factor: 2000
Power Cable: 16mm² (5 AWG) Audio Output Cable: 2 x 1.5 mm² (15 AWG)
Recommended Fuse (Music): 80A Recommended Battery: 80Ah
Width: 13.6 cm / 5.4 in Length: 18 cm / 7.1 in Height: 5.48 cm / 2.1 in Weight: 1.13 Kg.
